WSV-26.150-2
$0.00
WORKPIECE DIMENSIONS (AL-RIM)
Min/Max. Rim diameter: 14-26 in.
Max. Rim width: 17 in.
MACHINE DATA
AC-drive Motor: 300 kW
Speed of Main Spindle min.-1: 100-800
Tailstock Travel: 600 mm
Tailstock Force: 350 kN
Axial Slide Travel, Z-axis: 500 mm
Max. Axial Force Z-axis: 280 kN
Axial Speed Range, Z-axis: 0–5000 mm/min
Axial Rapid Speed, Z-axis: 8000 mm/min
Radial Slide Travel X-axis, (3 units): 225 mm
Max. Radial Force: 340 kN
Radial Speed Range, X-axis: 0–5000 mm/min
Radial Rapid Speed, X-axis: 8000 mm/min
Ejector Travel: 350 mm
Ejector Force: 200 kN
PLC Control: Siemens Step 7
CNC Control System: Siemens 840D
CNC Programming Software: SpinCAD™
