SPT-20.150
An aluminum liner spinning machine is a specialized piece of equipment designed for forming aluminum liners, which are typically used as the inner shells of composite pressure vessels, such as gas cylinders or tanks. The machine employs the metal spinning process, where a flat or cylindrical aluminum blank is gradually shaped into the desired liner form through high-speed rotation and controlled tooling
An aluminum liner spinning machine is a specialized piece of equipment designed for forming aluminum liners, which are typically used as the inner shells of composite pressure vessels, such as gas cylinders or tanks. The machine employs the metal spinning process, where a flat or cylindrical aluminum blank is gradually shaped into the desired liner form through high-speed rotation and controlled tooling
An aluminum liner spinning machine is a specialized piece of equipment designed for forming aluminum liners, which are typically used as the inner shells of composite pressure vessels, such as gas cylinders or tanks. The machine employs the metal spinning process, where a flat or cylindrical aluminum blank is gradually shaped into the desired liner form through high-speed rotation and controlled tooling
MAXIMUM CAPACITY
Diameter Range: 275-500 mm
Maximum Tube length 3000 mm
Maximum Wall Thickness 15 mm
MACHINE DATA
Spindle Drive AC Vector: 150 kW
Max. Spindle Speed: 400 Rpm
Z-axis speed: 0-125mm/sec
Z-axis force: 70kN
X-axis speed: 0-125mm/sec
X-axis force: 70kN
Chucking System Spring Chuck
Clamping force 190kN
CNC Control System: Siemens Sinumerik One
Programming Software: MJC Software Suite
